Quick Details

  • Place of Origin: Fujian, China (Mainland)
  • Brand Name: TID
  • Model Number: TM-558
  • Type: Vehicle Mouted
  • Dimensions: 160*43*143mm
  • Frequency Range: 136-520MHz
  • Storage Channel: 128
  • Talk Range: More than 60 km
  • Brand: TID
  • Color: Black
  • Warranty: 18 months
  • Output powe: VHF 60W/UHF 45W
  • Certificate: FCC/CE/ROSH
  • Repeater offset shift: Yes
  • Band setting: Wide/Narrow
  • Power selectable: High/mid/low
  • 2 tone/ 5 tone: Yes
  • Scrambler: Yes

Packaging & Delivery

Packaging Details TID standard packing
Delivery Time In 2 weeks after order confirmed, samples ready anytime

Specifications

TD-M558 60W Car Radio
1 DTMF/2 ton/5 tone
2.Microphone lock/ Mic programmable menu
3. talking range more than 60km

TD-M558 60W Car Radio

Main

Main functions:


01. Menu setting
02. Work by repeater station
03. Auto repeater offset frequency
04. Remote Kill/stun/activate/revive
05. Wide/Narrow band setting
06. Channel Name editing
07. CTCSS/DCS Setting& Scanning
08. High/Mid/Low Power selectable
09. Voice compander
10. Repeater offset shift
11. DTMF/2 ton/5 tone
12. Talk around
13. Voice prompt
14. Auto Power off
15. Scrambler
16. Emergency Alarm
17. COMP function
18. Scan function
19. 1750Hz tone
20. ANI ID
21.Microphone lock/ Mic programmable menu
22.Call keypad
23.200 channels



Specification:


Specification
Frequency range (TX)136-174MHz
 245-260MHz
 350-370MHz
 400-490MHz
 470-520Mhz
Frequency range (RX)136-174MHz
 245-260MHz
 350-370MHz
 400-490MHz
 470-520Mhz
Modulation modeF3E(FM)
Antenna impedance50Ω
Rated voltage13.8V DC ±15%
CurrentTransmitting    <12A
Receiving    <1.0A (Output 2W)
Frequency stability ≤±2.5PPm
Transmitting
Output powerVHF: 60W(H)   25W(Mid) 10W(Low)
 UHF: 40W(H)   25WMid) 10W(Low)
Reactance modulation  Reactance
Modulation limit25KHz±5KH, 12.5KHz±2.5KHz
Audio distortion<5%
Adjacent channel power25KHz≥65dB, 12.5KHz≥60dB
Stray radio frequency measure<-60dB
Modulation character3dB~-3dB (Modulation frequency: 300Hz~3KHz)
Receiving
CircuitryAdopt quadratic frequency conversion superheterodyne mode
Mid-frequency (1st/2nd)49MHz/450Khz
Sensitivity25KHz<0.2μV, 12.5KHz<0.25μV
Selectivityminus 6dB  25KHz<12KHz, 12.5KHz<10KHz
minus 60dB 25KHz<30KHz, 12.5KHz<24KHz
Same channel restrain>-8dB
Adjacent channel selective25KHz≥65dB, 12.5KHz≥60dB
Stray response anti-interference25KHz≥65dB, 12.5KHz≥60dB
Intermodulation anti-interference25KHz≥60dB, 12.5KHz≥55dB
Blocking≥90dB
Audio response1dB~-3dB (Modulation frequency: 300Hz~3KHz)
Audio distortion<5% (>2W)(Microphone internal resistance is 8Ω




Packing:



Package
Dimensions (L*W*H  flat part) : 145*47*190mm
Weight : 1.2kg


Standard Accessories
DC power cable
Programmable cable
Standard speaker or DTMF speaker





Pictures:
